PP strapping belt production line Single/twin screw PP strapping
belt extrusion equipment PP strapping belt making machine
Product Description of PP strapping production line:
PP strapping production line
The PP strapping tape production line is a professional equipment combination used to produce
polypropylene (PP) strapping belt. Through a series of continuous
process links, PP raw materials are converted into high-strength
and flexible strapping tape products. They are widely used in
logistics, packaging, building materials and other fields.
Raw materials-----100% polypropylene new or recycled material, or a mix.
Screw-----PP baling tape production line adopts special screw for extruder,
extruding uniformly.
Automatic screen changer------The 4-mesh recirculating large-area filter minimises the need for
frequent screen changes and ensures continuous, high-quality
production without interruption.
Line speed ----- PP baling belt production line adopts high speed operation, speed 200-300m/min.
Screw--------
The equipment adopts high-precision high-quality screws, adopts
well-known brands, and has unique parameter design. It has the
advantages of large extrusion volume, good plasticization, high
hardness and wear resistance; equipped with a quantitative
extrusion system, the width and thickness of the produced belts are
the same, the error range is small, and it meets the national
strapping tape acceptance standards;
EXTRUSION PARAMETERS TABEL
| Model | PP-2 | PP-4 | PP-6 | PP-8 | PP-10 | PP-12 |
| Raw material | PP polypropylene new material/recycled material |
| Number of tapes | 2 | 4 | 6 | 8 | 10 | 12 |
| Width(mm) | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 |
| Thickness(mm) | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 |
| Line speed(m/min) | ≧260-300 |
| PLC control system | PLC | PLC | PLC | PLC | PLC | PLC |
| Screw Model | 90 | 110 | 125 | 135 | 135 | 135 |
| Reducer model | 200 | 220 | 250 | 280 | 280 | 280 |
| Drying barrel (kg) | 100 | 150 | 200 | 200 | 200 | 200 |
| Winding machine | Automatic winding machine /Semi-automatic winding machine |
| Screen Changer | Automatic/Manua |
| Production capacity 24H | 2.5-3T | 6-7T | 8-9T | 10-11T | 12-13T | 13--14T |
PP STRAPPING BELT:
The primary material of PP strapping belt (polypropylene strapping belt) is polypropylene
(PP), with minor additives added depending on performance requirements.
1. Primary Materials
PP:
- Comprising over 95% of the tape's raw material, it is the core raw material.
- Features: Lightweight, abrasion-resistant, corrosion-resistant,
high tensile strength, and low cost.
2. Common Additives
To enhance performance, the following additives may be added during
production:
PP fillers (such as calcium carbonate):
- Reduce costs and increase hardness and density, but excessive
amounts can affect flexibility.
- PP masterbatch**:
- Provides colors (commonly available in green, white, red, black,
blue, yellow, and transparent) for easy identification or labeling.
- Anti-aging agents**:
- Extend the tape's lifespan during outdoor use and prevent UV
degradation.
Application Industry
Logistics industry--------PP strapping belt can ensure the secure bundling of cartons, wooden boxes, pallets
and other items, ensuring that your goods remain safe during
transportation.
Fruit industry----------PP strapping belt can ensure that fruit cartons, fruit plastic baskets, etc. are
firmly bundled to ensure transportation safety.
PP strapping belt is suitable for baling machines:
Fully automatic strapping machine
Semi-automatic strapping machine
High-speed ultra-thin strapping machine
Handheld electric strapping machine
Manual strapping machine (iron buckle)
About th SERVICE:
Installation and commissioning: Provide PP strapping tape production line and commissioning services.
Technical training: Provide professional operation training for
operators.
Maintenance: Regularly maintain and service the equipment to extend
its service life.
Technical support: Answer questions encountered by customers during
use and provide technical advice.
FAQ:
Q:What is the voltage of PP strapping tape production line?
A:380V/50HZ, we support customization
Q:What is the length of the PP strapping belt?
A: L:36 M.
Q:Where is the PP strapping tape production line?
A:We are from China.
Q:Can PP strapping tape production line provide after-sales service?
A:Yes, we have professional after-sales engineers who provide
24-hour online guidance.
Q:Is the quality of PP strapping tape production line?
A:We have 30 years of manufacturing experience, and have their own PP strapping tape production line plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping tape production line customization?
A:We are a manufacturing plant that can customize model size,
extrusion capacity, voltage and so on according to customer
requirements.
Q:What does the wrapping machine part of the PP strapping tape production linelook like?
A:Equipped with automatic wrapping machine/semi-automatic wrapping machine.
